CS45 / CS50 / CS56 Chainsaw
34
Original Instructions Version April 12
CS46 Parts - Engine Unit cont.
ID PART NUMBER DESCRIPTION
50 MIYD45.01.00-26 SPROCKET RIM
51 MIYD45.01.00.06-00 WORM
52 MIYD45.01.00-15 COVER PLATE
53 MIYD45.01.00.09-00 OIL SEAL 15X28X4.5
54 MIGB/T276 6202D BEARING 6202
GRADE D 15X35X11
55 MIYD45.01.00-8 CUSHION BLOCK
56 MIYD45.01.00-7 CHOKE ROD
MOUNTING
57 MIYD45.01.00.03-00 CHOKE ROD
58 MIYD45.01.00-11 ANTI-VIBRATION
MOUNT
59 MIYD45.01.00.07-00 ANTI-VIBRATION
MOUNT
60 MIYD45.01.00.01-00 AIR INTAKE TUBE
SUPPORT
61 MIYD45.01.00-4 TIE PLATE
62 MIYD45.01.00-3 SEALING PLATE
63 MIYD45.01.00-14 AIR INTAKE TUBE
GASKET
64 MIYD45.01.06-00 CARBURETTOR
65 MIYD45.01.00.02-00 AIR INTAKE SOCKET
66 MITCS4600.01.08-00 AIR FILTER
67 MIGB/T899 GM5-
M5X30
DOUBLE-SCREW
BOLT GM5-M5X30
68 MIYD45.01.00-5 CUSHION
69 MIGB/T2672 M5X50 SCREW M5X50
70 MIYD45.01.01.02-1M R/H CASE (MAGNE-
SIUM)
71 MIYD45.01.00-6 DUST PLATE
72 MIGB/T119.2 5X10 PIN 5X10
ID PART NUMBER DESCRIPTION
73 MIYD38-3.01.11.03-00 GROUND WIRE
74 MIYD45.01.00-10 ANTI-VIBRATION
MOUNT
75 MIGB/T6191 M5X25 SCREW M5X25
76 MIYD45.01.00-20 SEAL SHIELD
77 MIGB/T93 M4 WASHER M4
78 MIGB/T2672 M4X8 SCREW M4X8
79 MIGB/T2672 M4X10 SCREW M4X10
80 MIYD45.01.10.01-00A FLYWHEEL AS-
SEMBLY
81 MIGB/T6177.2 M8X1 NUT M8X1
82 MITCS4600.03.03-00 OIL CAP ASSEMBLY
83 MIYD38-3.03.02-2 RETAINER
85 MIYD45.01.01.01-3 CIRCLIP
86 MIYD45.01.01.01-2 OIL PIPE 2.5X6X105
87 MIYD45.01.01.03-00 VACUM JOINT
88 MIYD45.01.01.01-1M L/H CASE (MAGNE-
SIUM)
89 MIGB/T893.1 35 CIRCLIP (SIZE 35)
90 MIYD45.01.00.08-00 OIL SEAL 15X35X4.5
91 MIYD45.01.11.01-00 IGNITION COIL
92 MIYD45-7.01.11.02-00 GROUND WIRE
93 MITCS4600.01.11-3 IGNITION SHEILD
94 MIYD45.00.00-9 DUST COVER
95 MIYD45.01.01-1 CRANKCASE
GASKET
96 MIYD45.01.00-18 DAMPER
97 MIYD06.06.186 DECOMPRESSOR
98 D20-WAT CARB GASKET KIT
