CS45 / CS50 / CS56 Chainsaw
36
Original Instructions Version April 12
CS50 Parts - Engine Unit cont.
ID PART NUMBER DESCRIPTION
1 MIYD50.01.02-1 CYLINDER
2 MIGB/T6170 M5 NUT M5
3 MIGB/T93 M5 SPRING WASHER M5
4 MIGB/T97.1 M5 WASHER M5
5 MIYD45.01.09-1 MUFFLER COVER
PLATE
6 MIYD45.01.09.01-00E2 MUFFLER - EU2
SPEC
7 MIYD45.01.00-2 MUFFLER GASKET
8 MIYD45.01.00-24 MUFFLER CON-
NECTING SCREW
9 MIGB/T6191 M5X20 SCREW M5X20
10 MISPRCJ6Y SPARK PLUG (CHAM-
PION RCJ6Y)
11 MIYD50.01.02.03 SPRING
12 MIYD50.01.02.02 AIR INTAKE TUBE
13 MIGB/T2672 M5X12 SCREW M5X12
14 MIYD45.01.00-17 O-RING
15 MIYD45.01.00-1 CYLINDER GASKET
16 MIYD50.01.03-2 PISTON RING
17 MIYD50.01.03.00-00 PISTON
18 MIYD45.01.03-4 PISTON PIN CIRCLIP
19 MIYD50.01.03-3 PISTON PIN
20 MIYD45.01.03-5 NEEDLE BEARING
RING
21 MIYD45.01.03.01-00 CRANKSHAFT
22 MIYD45.01.03.02-00 NEEDLE BEARING
11X15X12.5
23 MIGB/T1099 3X3.5X10 SEMI-CIRCULAR KEY
3X3.5X10
24 MIYD45.00.00-4 CONICAL ANTI-
VIRATION SPRING
ID PART NUMBER DESCRIPTION
25 MIYD45.00.00-3 ANTI-VIBRATION
SPRING BASE
26 MIGB/T845 ST4.8X16 TAPPING SCREW
ST4.8X16
27 MIYD45.00.00.01-00 CHAIN CATCHER
28 MIGB/T2672 M5X16 SCREW M5X16
29 MIYD45.01.01.02-2 BREATHER JET
30 MIYD45.01.01.02-3 CIRCLIP
31 MIYD45.01.00-22 SPONGE BREATHER
32 MIYD45.01.00-21 FELLING DOG
33 MIGB/T2672 M5X10 SCREW M5X10
34 MIYD45.01.00.04-2 OIL FILTER SCREEN
35 MIYD45.01.00.04-1 OIL FILTER
36 MIYD45.01.00-12 OIL TUBE
37 MIGB/T2672 M4X14 SCREW M4X14
38 MIYD45.01.15-00 OIL PUMP
39 MIYD45.01.00-23 SPONGE
40 MIYD45.01.00-13 OIL OUTLET PIPE
41 MIYD45.01.00-16 CHAIN GUIDE
BLOCK
42 MIGB/T900 M8X26-8.8 DOUBLE-SCREW
BOLT AYM8-
M8X26-8
43 MIYD45.01.13.01-00 CLUTCH ASSEMBLY
46 MIYD45.01.13.01-3 CLUTCH SPRING
47 MIYD45.01.00-19 CLUTCH ADJUSTING
WASHER
48 MIYD45.01.00.10-00 NEEDLE BEARING
12X15X14.5
49 MIYD45.01.13-1 CLUTCH DRUM
