CS56 Parts - Engine Unit
ID PART NUMBER DESCRIPTION
1 MIYD56.01.02-1 CYLINDER
2 MIGB/T6170 M5 NUT M5
3 MIGB/T93 M5 SPRING WASHER
M5
4 MIGB/T97.1 M5 WASHER M5
5 MIYD45.01.09.01-00 MUFFLER
6 MIYD45.01.00-2 MUFFLER GASKET
7 MIYD45.01.00-24 MUFFLER CON-
NECTING SCREW
8 MIGB/T6191 M5X20 SCREW M5X20
9 MISPRCJ6Y SPARK PLUG
(CHAMPION RCJ6Y)
10 MIYD45.01.02-2 AIR INTAKE TUBE
GASKET
11 MIYD45.01.02.01-00 AIR INTAKE TUBE
12 MIGB/T2672 M5X12 SCREW M5X12
13 MIYD45.01.00-17 O-RING
14 MIYD45.01.00-1 CYLINDER GASKET
15 MIYD56.01.03-2 PISTON RING
16 MIYD56.01.03-1 PISTON
17 MIYD45.01.03-4 PISTON PIN CIRCLIP
18 MIYD56.01.03-3 PISTON PIN
19 MIYD56.01.03-5 NEEDLE BEARING
RING
20 MIYD45.01.03.01-00 CRANKSHAFT
21 MIYD45.01.03.02-00 NEEDLE BEARING
11X15X12.5
22 MIGB/T1099 3X3.5X10 SEMI-CIRCULAR
KEY 3X3.5X10
23 MIYD45.00.00-4 CONICAL ANTI-
VIBRATION SPRING
ID PART NUMBER DESCRIPTION
24 MIYD45.00.00-3 ANTI-VIBRATION
SPRING BASE
25 MIGB/T845 ST4.8X16 TAPPING SCREW
ST4.8X16
26 MIYD45.00.00.01-00 CHAIN CATCHER
27 MIGB/T2672 M5X16 SCREW M5X16
28 MIYD45.01.01.02-2 BREATHER JET
29 MIYD45.01.01.02-3 CIRCLIP
30 MIYD45.01.00-22 SPONGE BREATHER
31 MIYD45.01.00-21 FELLING DOG
32 MIGB/T2672 M5X10 SCREW M5X10
33 MIYD45.01.00.04-2 OIL FILTER SCREEN
34 MIYD45.01.00.04-1 OIL FILTER
35 MIYD45.01.00-12 OIL TUBE
36 MIGB/T2672 M4X14 SCREW M4X14
37 MIYD45.01.15-00 OIL PUMP
38 MIYD45.01.00-23 SPONGE
39 MIYD45.01.00-13 OIL OUTLET PIPE
40 MIYD45.01.00-16 CHAIN GUIDE
BLOCK
41 MIGB/T900 M8X26-8.8 DOUBLE-SCREW
BOLT AYM8-
M8X26-8
42 MIYD45.01.13.01-00 CLUTCH ASSEMBLY
45 MIYD45.01.13.01-3 CLUTCH SPRING
46 MIYD45.01.00-19 CLUTCH ADJUST-
ING WASHER
47 MIYD45.01.00.10-00 NEEDLE BEARING
12X15X14.5
48 MIYD45.01.13-1 CLUTCH DRUM
49 MIYD45.01.00-26 SPROCKET RIM
