Specications / Items sold separately
● LM55P4(W)
Model LM55P4(W)
Viewable size 1209.6 x 680.4 mm (54.6 inches)
Resolution 1920 x 1080 pixels
PC Input / Output
Input connector
Analog MINI D-Sub 15 pin
Digital
DVI-D (HDCP supported), DisplayPort
Output connector Digital DisplayPort
AV Input / Output Input connector HDMI
Option slot Slot interface Digital (OPS) slot (12V / 4.0A)
External control
Input connector
RS-232C <2.5 mm Phone Jack>
Network: RJ45 (10BASE-T / 100BASE-TX)
Output connector RS-232C <2.5 mm Phone Jack>
Push-button Standby switch (
) (ON/STANDBY)*
Power consumption 300 W (TBD)
Power supply AC 100 V – 240 V 50/60 Hz 3.0 A (TBD)
External
dimensions
(excluding
protrusions)
Width 1210.5 mm (47.7 inches)
Height 681.2 mm (26.8 inches)
Depth
98 mm (3.9 inches)
(103.4mm (4.1inches) *Including handle)
Operating temperature and humidity
5˚C – 35˚C (41˚F – 95˚F)
20 % – 80 % (without condensation)
Weight
25.0 kg (55.1 lbs)(TBD)
Accessories
User’s Manual, DisplayPort cable (1.8 m),
RS-232C cable (D-Sub 9 pin - 2.5 mm Phone Jack / 1.8 m),
Daisy chain cable (2.5 mm Phone Jack / 4m), Band (7 pcs.)
* When the button is pressed and held, the status is changed between power ON and standby.
Option
● Remote control kit : DP-02RK
● Wall mount bracket : BR-LM1KK
● OPS module : VC-LM1HD, DP-1SDI-3G
● Power cord (for North America) : JC-PC3MA (AC100 - 120 V)
● Power cord (for Japan) : JC-PC3MJ (AC100 V)
● Power cord (for Europe) : JC-PC3ME (AC200 - 240 V)
● Power cord (for Russia) : JC-PC3MR (AC220 V)
Recommended OPS computer : Advantech DS280GB1701E-T
Design and specications are subject to change without notice.
Digital

Mitsubishi Electric LM55P4 Specifications

General

Brand	Mitsubishi Electric
Model	LM55P4
Category	Monitor
Language	English
