Mitsubishi Electric MS-GD80VB-E1 - Unit Specifications; Noise Criteria Curves

3
SPECIFICATION
3
NOTE: Test conditions are based on ISO 5151.
Cooling: Indoor Dry-bulb temperature 27°C Wet-bulb temperature 19°C
Outdoor Dry-bulb temperature 35°C Wet-bulb temperature 24°C
Indoor-Outdoor piping length: 5 m
Indoor model
Function
Power supply
Air flow
(High/Med./Low)
Running current
Breaker capacity
Power input
Power factor
Fan motor current
Model
Dimensions W × H × D
Weight
Air direction
Sound level
(High/Med./Low)
Fan speed (High/Med./Low)
Fan speed regulator
Remote controller model
Fan Electrical
datamotor
Special remarks
Cooling
Single phase
230 V, 50 Hz
954/822/684
0.34
10
69
88
0.34
RC4V40-AA
1,100 × 325 × 258
16
5
47/42/37
1,280/1,130/970
3
KM04B
/h
A
A
W
%
A
mm
kg
dB
rpm
MS-GD80VB
NOISE CRITERIA CURVES
4
90
80
70
60
50
40
30
20
10
63 125 250 500 1000 2000 4000 8000
OCTAVE BAND SOUND PRESSURE LEVEL, dB re 0.0002 MICRO BAR
BAND CENTER FREQUENCIES, Hz
APPROXIMATE
THRESHOLD OF
HEARING FOR
CONTINUOUS
NOISE
NC-60
NC-50
NC-40
NC-30
NC-20
NC-70
Test conditions,
Cooling : Dry-bulb temperature 27˚C Wet-bulb temperature 19˚C
47
SPL(dB(A)) LINE
High
FAN SPEED
MS-GD80VB
INDOOR UNIT
WALL
MICROPHONE
0.8m
1m
OBH511A
