En-18
SPECIFICATIONS
Wi-Fi interface
Model MAC-568IFB3-E
Input Voltage DC12.7 V (from indoor unit)
Power consumption MAX 2 W
Size H×W×D (mm) 79×44×18.5
Weight (g) 60 (including cable)
Transmitter power level (MAX) 17.5 dBm @IEEE 802.11b
RF channel 1ch ~ 13ch (2412~2472 MHz)
Radio protocol IEEE 802.11b/g/n (20)
Encryption AES
Authentication WPA2-PSK
Software Version XX.00
Wi-Fi interface setting information
Indoor unit model name
Indoor unit serial number
Outdoor unit model name
Outdoor unit serial number
Wi-Fi interface MAC address (MAC)
Wi-Fi interface serial number (ID)
Wi-Fi interface PIN (PIN)
Wi-Fi interface SSID (SSID)
Wi-Fi interface KEY (KEY)
System commissioning date
Wi-Fi interface installation date
Installer contact details
Name
Telephone number
MEMO
Indoor Outdoor
Cooling
Upper limit
32°C DB
23°C WB
46°C DB
Lower limit
21°C DB
15°C WB
-10°C DB
Heating
Upper limit
27°C DB
24°C DB
18°C WB
Lower limit
20°C DB
-15°C DB
-16°C WB
Guaranteed operating range
DB : Dry Bulb
WB : Wet Bulb
JG79Y333H01_6th.indd 18 2018/06/19 10:28:22

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mitsubishi Electric MSZ-AP42VGD and is the answer not in the manual?

Mitsubishi Electric MSZ-AP42VGD Specifications

General IconGeneral
Cooling Capacity4.2 kW
Heating Capacity5.0 kW
Power Supply220-240V, 50Hz
Weight (Indoor Unit)9 kg
Weight (Outdoor Unit)34 kg
RefrigerantR32
Outdoor Unit Weight34 kg
Indoor Unit Weight9 kg
TypeSplit System
