Mitsubishi Electric MSZ-SF50VE Service Manual

10
MSZ-SF25VE
MSZ-SF25VE2
MSZ-SF25VE3
90
80
70
60
50
40
30
20
10
63 125 250 500 1000 2000 4000 8000
NC-60
NC-50
NC-40
NC-30
NC-20
NC-70
OCTAVE BAND SOUND PRESSURE LEVEL, dB re 0.0002 MICRO BAR
BAND CENTER FREQUENCIES, Hz
COOLING
FUNCTION
SPL(dB(A))
LINE
Super High
FAN SPEED
HEATING
42
46
NC-10
MSZ-SF35VE
MSZ-SF35VE2
MSZ-SF35VE3
90
80
70
60
50
40
30
20
10
63 125 250 500 1000 2000 4000 8000
NC-60
NC-50
NC-40
NC-30
NC-20
NC-70
OCTAVE BAND SOUND PRESSURE LEVEL, dB re 0.0002 MICRO BAR
BAND CENTER FREQUENCIES, Hz
COOLING
FUNCTION
SPL(dB(A))
LINE
Super High
FAN SPEED
HEATING
42
45
NC-10
NOISE CRITERIA CURVES
4
Test conditions
Cooling: Dry-bulb temperature 27°C
Wet-bulb temperature 19°C
Heating: Dry-bulb temperature 20°C
Wet-bulb temperature 15°C
INDOOR UNIT
WALL
MICROPHONE
0.8m
1m
MSZ-SF42VE
MSZ-SF42VE2
MSZ-SF42VE3
90
80
70
60
50
40
30
20
10
63 125 250 500 1000 2000 4000 8000
NC-60
NC-50
NC-40
NC-30
NC-20
NC-70
OCTAVE BAND SOUND PRESSURE LEVEL, dB re 0.0002 MICRO BAR
COOLING
FUNCTION
SPL(dB(A))
LINE
Super High
FAN SPEED
HEATING
45
49
NC-10
MSZ-SF50VE
MSZ-SF50VE2
MSZ-SF50VE3
90
80
70
60
50
40
30
20
10
63 125 250 500 1000 2000 4000 8000
NC-60
NC-50
NC-40
NC-30
NC-20
NC-70
OCTAVE BAND SOUND PRESSURE LEVEL, dB re 0.0002 MICRO BAR
BAND CENTER FREQUENCIES, Hz
COOLING
FUNCTION
SPL(dB(A))
LINE
Super High
FAN SPEED
HEATING
42
47
NC-10
OBH600E

Mitsubishi Electric MSZ-SF50VE Specifications

General

Cooling Capacity	5.0 kW
Energy Efficiency Rating (Cooling)	A++
Power Supply	220-240V, 50Hz
Outdoor Unit Dimensions (W x H x D)	800 x 550 x 285 mm
Weight (Outdoor Unit)	35 kg
Refrigerant	R32
Outdoor Unit Noise Level	50 dB
Type	Split System Air Conditioner
