Mitsubishi Electric PUHZ-P125YHA Technical Data Book

48
5
REFRIGERANT SYSTEM DIAGRAM
PKA-RP·HAL
PKA-RP·KAL
Thermistor TH2
Pipe temperature(Liquid)
Distributor with strainer
(#50/#50: HAL)
(#50/#100: KAL)
Thermistor TH5
(Cond./ Eva.temperature)
Thermistor TH1
(Room temperature)
Refrigerant flow in cooling
Refrigerant flow in heating
Strainer (#50)
Strainer (#50)
Heat exchanger
Refrigerant GAS pipe connection
(Flare)
Refrigerant LIQUID pipe connection
(Flare)
5-1. INDOOR UNIT
PLA-RP·BA/BA2/BA3 PEAD-RP·JA(L)
PCA-RP·KA PCA-RP·HA PSA-RP·GA
Thermistor TH2
Pipe temperature (Liquid)
Distributor
with strainer(#50)
Thermistor TH5
(Cond./Eva. temperature)
Thermistor TH1
(Room temperature)
Refrigerant flow in cooling
Refrigerant flow in heating
Strainer(#50)
Strainer(#50)
Heat exchanger
Refrigerant GAS pipe connection
(Flare)
Refrigerant LIQUID pipe connection
(Flare)
