36
3Press SWP1 or SWP2 to display the operation result (flow rate characteristic) corresponding each flow rate code
‘dxx’ in Table 1 and write them down.
Table 1
<Check result>
4Check the following.
↓ Check the checkbox.
□ All places with flow rate valve opening 1000 through 100 are 2 L or above?
If 2 L/min or below, air may not be bled out. Perform an air bleeding operation and water flow rate
adjustment operation again.
□ When there are multiple units, the values of the same pump output opening and the same valve opening
are not greater or less than those for other units by 10% and 2 L/min or more.
(In multiple-unit system, perform a water flow rate adjustment operation at the same time.)
□ All the values (item codes d01 through d09) are not “0” when the pump output opening is 16%. (Not
whole air is bled out.)
(Note 1) Change SW2-9 and SW2-3 as a stopgap procedure as shown in the table below, and then turn the power
on.
(Note 2) The table below shows the water flow rate adjustment operation status in 4 figures when the PCB DIP
switch is set as shown in Note 3.
(Note 3) PCB DIP switch settings
Close <------------------ Water flow rate adjust valve opening ------------------> Open
Pump output opening/water flow rate
adjust valve opening
1600 1400 1200 1000 800 600 400 200 100
Flow rate (pump output opening 16%) d01 d02 d03 d04 d05 d06 d07 d08 d09
Flow rate (pump output opening 27%) d10 d11 d12 d13 d14 d15 d16 d17 d18
Flow rate (pump output opening 100%) d19 d20 d21 d22 d23 d24 d25 d26 d27
Close <------------------ Water flow rate adjust valve opening ------------------> Open
Pump output opening/water flow rate
adjust valve opening
1600 1400 1200 1000 800 600 400 200 100
Flow rate (pump output opening 16%)
Flow rate (pump output opening 27%)
Flow rate (pump output opening 100%)
Multiple unit change-over switch
SW2-9
Local/internal change-over switch
SW2-3
When startup operation has not completed OFF ON
When startup operation has completed - -
Water flow rate adjustment operation status Display
Not completed - - n g
Completed - - - g
In operation - i n g
SW2 SW3
-10-5-6-7-8-9-10
ON OFF OFF OFF ON ON OFF
