Page 46
MODELS: WD-60C10 / WD-65C10 / WD-73C10 / WD-60638 / WD-65638 / WD-73638 /
WD-60738 / WD-65738 / WD-73738 / WD-82738 / WD-65838 / WD-73838 / WD-82838
Ref P/N Part Name & Description

# Ref P/N Part Name & Description

#
[ # ] Model Legend: (a) WD-60638, (b) WD-60738, (c) WD-60C10, (d) WD-65638, (e) WD-65738, (f) WD-65838, (g) WD-65C10,
(h) WD-73638, (i) WD-73738, (j) WD-73838, (k) WD-73C10, (l) WD-82738, (m) WD-82838
[] Safety Critical Part - Use exact replacement only
INTEGRATED CIRCUITS
IC1B01 271P349010 IC - MIC2005-0.5YM6
IC1B05 271P349010 IC - MIC2005-0.5YM6 befijlm
IC1B06 276P578020 IC-C-MOS - MM3376A33NRE fjm
IC2A01 276P726020 IC-C-MOS - 276P726 befijlm
IC2A01 276P829010 IC-C-MOS - PS331QFN64G acdghk
IC3A00 271P348010 IC - YDA164 abcdeghikl
IC3C00 276P741010 IC-C-MOS - AK4420ETP beil
IC3F01 276P515010 IC-C-MOS - DIR9001PWR fjm
IC3G01 276P513010 IC-C-MOS - D708E001BRFP266 fjm
IC3H01 276P827010 IC-C-MOS - K4S641632N fjm
IC3J01 271P326020 IC - NJM2831F05 fjm
IC3J02 271P355010 IC - NJM2781V fjm
acdfghjkm
IC3J03 271P345010 IC - NJM2753V fjm
IC3J04 276P503010 IC-C-MOS - AK5358AETP fjm
IC3L01 276P828010 IC-C-MOS - PCM1681PWPR fjm
IC3L02 276P828010 IC-C-MOS - PCM1681PWPR fjm
IC3L03 276P741010 IC-C-MOS - AK4420ETP fjm
IC3L05 276P741010 IC-C-MOS - AK4420ETP fjm
IC3M01 276P831010 IC-C-MOS - TPA2017D2V2RTJR fjm
IC3M02 276P831010 IC-C-MOS - TPA2017D2V2RTJR fjm
IC3M03 276P831010 IC-C-MOS - TPA2017D2V2RTJR fjm
IC3M04 276P831010 IC-C-MOS - TPA2017D2V2RTJR fjm
IC3N01 276P831010 IC-C-MOS - TPA2017D2V2RTJR fjm
IC3N02 276P831010 IC-C-MOS - TPA2017D2V2RTJR fjm
IC3N03 276P831010 IC-C-MOS - TPA2017D2V2RTJR fjm
IC3N04 276P831010 IC-C-MOS - TPA2017D2V2RTJR fjm
IC3P01 271P254010 IC - ISL6545ACBZ-TS2698 fjm
IC4A01 276P742020 IC-C-MOS - PST8428NR befijlm
IC4A01 276P823010 IC-C-MOS - BCM35143 acdghk
IC4A02 276P687030 IC-C-MOS - BCM3549SLKFSB5G befijlm
IC4A02 276P744010 IC-C-MOS - NT5TU64M16DG-AC acdghk
IC4A03 276P551010 IC-C-MOS - AT24C02BN-SH-T acdghk
IC4A04 276P825010 IC-CMOS - MX25L6405DMI-12G acdghk
IC4A05 271P345010 IC - NJM2753V acdghk
IC4A06 276P578040 IC-C-MOS - MM3376A18NRE acdghk
IC4A07 276P578030 IC-C-MOS - MM3376A10NRE acdghk
IC4A08 271P319020 IC - MM1701JHBE acdghk
IC4A09 276P578020 IC-C-MOS - MM3376A33NRE acdghk
IC4F01 276P744010 IC-C-MOS - NT5TU64M16DG-AC befijlm
IC4F02 271P033020 IC - LP2996LQNOPB befijlm
IC4F03 276P744010 IC-C-MOS - NT5TU64M16DG-AC befijlm
IC4G01 271P251040 IC - MM1662FHBE befijlm
IC4K01 276P832020 IC-C-MOS - NAND2GW3B2DZA6E befijlm
IC5A01 276P722010 IC-C-MOS - UPD808526F1
IC5A02 271P319010 IC - MM1701AHBE
IC5A03 271P319010 IC - MM1701AHBE
IC7A01 276P576010 IC-C-MOS - UPD78F1178GF(S)
IC7A03 276P578020 IC-C-MOS - MM3376A33NRE
IC7E01 276P519010 IC-C-MOS - 74HC132DB fjm
IC8300 276P525010 IC-C-MOS - MAX4489ASA+T fjm
IC9010 267P324010 HIC - STR-W6756

IC9020 271P142010 IC - RT9H301C

IC9030 271P315010 HIC - STR-A6159

IC9031 271P142010 IC - RT9H301C

IC9A01 271P254010 IC - ISL6545ACBZ-TS2698
IC9A02 270P950010 IC - NJM78M09DL1A(TE1) befijlm
IC9A02 271P254010 IC - ISL6545ACBZ-TS2698 acdghk
IC9A03 271P254010 IC - ISL6545ACBZ-TS2698 acdghk
IC9A03 271P323010 IC - ISL8014IRZ-T befijlm
IC9A04 271P323010 IC - ISL8014IRZ-T befijlm
IC9A04 276P578020 IC-C-MOS - MM3376A33NRE acdghk
IC9A05 271P323010 IC - ISL8014IRZ-T befijlm
IC9A06 271P321010 IC - PST8242NR
IC9A07 271P321010 IC - PST8242NR
IC9A08 276P578020 IC-C-MOS - MM3376A33NRE befijlm
IC9G80 271P349010 IC - MIC2005-0.5YM6
TRANSISTORS
CHIP Type Transistors (Listed by Part No.)
Part No. Description
261P805010 FDV301N
261P842080 2SC3052-T112-1E;F
261P844010 RT1N436C-T112-1
261P845010 RT1P241C-T1112-1
261P874010 FDS8896
261P875010 FDS8984
261P876010 FDS6298
261P877010 FDC655BN
261P878010 RT3Y97M-T111-1
261P881010 2SB1424T100R
261P889010 ISA1235AC1-T112A-1E,1F
261P918010 FDS6910
DIODES
D2A11 262P904070 DIODE-CHIP - DZ2J051M0L
D2A12 262P830010 D-CHIP - MC2850-T111-1
D2A13 262P830010 D-CHIP - MC2850-T111-1
D2A21 262P904070 DIODE-CHIP - DZ2J051M0L
D2A22 262P830010 D-CHIP - MC2850-T111-1
D2A23 262P830010 D-CHIP - MC2850-T111-1
D2A31 262P904070 DIODE-CHIP - DZ2J051M0L
D2A32 262P830010 D-CHIP - MC2850-T111-1
D2A33 262P830010 D-CHIP - MC2850-T111-1
D2A41 262P904070 DIODE-CHIP - DZ2J051M0L fjm
D2A42 262P830010 D-CHIP - MC2850-T111-1 fjm
D2A43 262P830010 D-CHIP - MC2850-T111-1 fjm
D4A05 262P830010 D-CHIP - MC2850-T111-1 befijlm
D4A06 262P830010 D-CHIP - MC2850-T111-1 befijlm
D4A07 262P830010 D-CHIP - MC2850-T111-1 befijlm
