MODELS: WS-48313 / WS-48413 / WS-55313 / WS-55413 / WS-65313 / WS-65413
QUICK REFERENCE FOR COMMON REPLACEMENT PARTS
REMOTE CONTROL
260P11601 Remote Control WS-48313 / WS-55313 / WS-65313
260P117010 Remote Control WS-48413 / WS-55413 / WS-65413
HIGH VOLTAGE / DEFLECTION COMPONENTS
Q5A51 261P082010 HV-OUT 2SK2771-O1R
T5A51 334P281010 TRANS-FLYBACK
330P293010 DEFL-YOKE WS-55413 / WS-65313 / WS-65413
330P293020 DEFL-YOKE WS-48313 / WS-48413 / WS-55313
453B136010 CAP-ANODE-LONG [R]
453B136020 CAP-ANODE-LONG [GB]
CRT-ASSY
WS-48313
WS-48413
WS-55313
WS-55413
WS-65313
WS-65413
ASSY-CRT-RED
251C222070
251C223040
251C223010
251C223070
251C222040
251C222040
ASSY-CRT-GREEN
251C222080
251C223050
251C223020
251C223080
251C222050
251C222050
ASSY-CRT-BLUE
251C222090
251C223060
251C223030
251C223090
251C222060
251C222060
CRT ASSEMBLIES
PCB WS-48313 WS-48413 WS-55313 WS-55413 WS-65313 WS-65413
MAIN
930B899003
ç ç
930B899001
ç ç
POWER
930B90001
ç ç ç ç ç
SIGNAL
930B901001-48 930B901002-48 930B901001-55 930B901002-55 930B901001-65 930B901002-65
TERMINAL
93B0902001
ç ç ç ç ç
CRT
934C062001
ç ç ç ç ç
DOUBLER
934C063001
ç ç ç ç ç
PREAMP
935D738001 935D738002 935D738001 935D738002 935D738001 935D738002
FRONT
935D739001
ç ç ç ç ç
CONTROL
935D740001
ç ç ç ç ç
PRINTED CIRCUIT BOARDS
LENTICULAR
FRESNEL
MODEL
MIRROR
SCREEN
LENS
WS-48313
767D072040 491P138020 491P139020
WS-48413
" " "
WS-55313
767D072050 491P103030 491P104030
WS-55413
767D072030 " "
WS-65313
767D048090 491P105050 491P106080
WS-65413
" " "
MISCELLANEOUS
\
