Mitsubishi Heavy Industries FDC280KXZE1 User Manual

-
129
-
'14 • KX-SM-202

Function of Dip switch for control (SW3, 4, 5)
• SW3 (Function setting)

Function of Jumper wire (J13, 15)
(With: Shorted / None: Opened)
• SW5 (Function setting)
Switch Function
SW3-1
ON Inspection LED reset
OFF Normal
SW3-2
ON Backup operation
OFF Normal
SW3-4
ON Refrigerant quantity check
OFF Normal
SW3-5
ON Check operation start
OFF Normal
SW3-7
ON Forced cooling/heating
OFF Normal
Jumper Function
J13
With External input Level input
None External input Pulse input
J15
With Defrost start temperature Normal
None Defrost start temperature Cold weather region
• SW4 (Model selection)
Switch
Model
SW4
1 2 3 4
FDC280 ON OFF OFF OFF
FDC335 OFF ON OFF OFF
FDC400 OFF OFF ON OFF
FDC450 ON OFF ON OFF
FDC475 ON ON OFF OFF
FDC500 OFF ON ON OFF
FDC560 ON ON ON OFF
• SW4 (Master/Slave setting)
Outdoor unit SW4-7 SW4-8
Master OFF OFF
Slave 1 ON OFF
Slave 2 OFF ON
ON/OFF Function
SW5-1
ON Test run switch test run
OFF Test run switch Normal
SW5-2
ON Test run operation mode Cooling
OFF Test run operation mode Heating
SW5-3
ON Pump down switch Pump down
OFF Pump down switch Normal
SW5-5
ON Superlink protocol : Previous SL
OFF Superlink protocol : New SL
• SW7,8,9 (Function setting)
Switch Function
SW7 Data erase/data write
SW8 7-segment display No. UP order of 1
SW9 7-segment display No. UP order of 10
