Mitsubishi 1540 FD User Manual

Belt length and size
Size “A” 37.25” long
Granger 3L370
NAPA
NBH 257370
Belt Angle : 36
Belt Imperial Length : 37.56" (954 mm)
Belt Top Width : .41" (10 mm)
Fuel System
Fuel …………………………
………
………………..
Wax Type (if installed)
Fuel Injection Pump …….……………………
0.6 kg/cm2 (8.5 psi)
Injection nozzle ………….……………………..
Centrifugal impeller type
Fuel filter
…………………………………………..
Paper element type
Feul Tank……………………
………………………
18 L (4.7 GAL.)
Lubrication System
Oil Pump
……………………
….
………………..
Trochoid type pump
Oil Filter
.……………………
……………………
Paper Element filter type cartridge NAPA 1334
Oil Pressure
…………….……………………..
6 kg/cm2 (85.3 psi)
Oil Capacity……………………………………..
3 L
(3.2 QT.)
Air Cleaner
Type
……………………………………..
Cyclone dry air cleaner (NAPA 6270 modified by
switching the plastic cyclone to the other end of
the filter)
Filter
.……………………
Dry paper element
Governor
Type
……………………………………..
Centrifugal weight type
Electrical System
Battery ……………………………………………….
G100
-
S6 Polymion 12v
–
45 Ah
Generator
…
………………..
.……………………
12 V
–
15 A
Starting Motor
……
…
…….……………………..
12 V
–
1.6 kw Magnet type

Mitsubishi 1540 FD Specifications

General

Brand	Mitsubishi
Model	1540 FD
Category	Tractor
Language	English
