Mitsubishi 1540 FD User Manual

Turing Radius (without brake)
2000
mm (81.0 in)
2450mm (96.0 in)
Clutch
Clutch type
…
….
…………………………………..
Dry single disk plate
Torque capacity
.……
…..
…
……….
……………
9.42 kg
-
m (68.1 ft/lb)
Transmission
Number of shift levers .
……………………….
2
Speed steps .
………………..
.……………………
6
-
forward, 2
-
Rreverse
Speed change method..
……………………..
Selective sliding gear type
Differential gear
.
….…………………………….
Bevel gear type
Diff
erential lock
………………………………….
With differential lock
Capacity Diff and Rear carrier……………..
12 L
(21.2 QT.)
Power Take Off
Power take off shaft ………………………
….
18 spline 25 mm
PTO Horse power ………………………….….
.
1
5
.
2
Hp @ 2,700 engine rpm
PTO Shaft speed…………………
………………
.
565 rpm, 832 rpm, 1364 rpm
@2,700 engine rpm
Standard PTO speed (L)
……………………
..
540 rpm @2,580 engine rpm
?
Standard PTO speed (
M
)
……………………..
1000 rpm @ 1,979 engine rpm
?
Standard PTO speed (H) ……………………
..
1000 rpm @ 1,979 engine rpm
?
Directi
on of rotation .………………………
….
Clockwise as viewed from the rear
Max. Torque……………………………………
…..
4.2 kg
-
m (30.4ft
-
lb) @ 1800 rpm
?
Brake
Brake type
…
….
…………………………………..
Foot operated internal expansion waterproof dry
type
Parking Brake
.……
……..
…
……….
……………
Main
brake use hand operating lock type
Steering
Steering type (2
-
WD) ………………………….
Worm and sector type
(4
-
WD)……….
…………………
Ball screw type
Toe
-
in (2WD & 4WD)
………………
…
……..
6mm +_ 2mm (5/32in ~10/32in)
Hydraulic System (Mitsubishi live hydraulic system)
Control
...
…………………………………………….
Lift, hold, down, flow control and lift lock
Type
of cylinder .…
……………………………..
Single acting cylinder
