12-72 Simple inspection and service
4. Jack up the vehicle until the tire is just clear of
the ground.
5. Remove the wheel nuts and then the tire.
6. To remove the tires of a rear dual-wheel, first
loosen the outer wheel nuts and remove outer
tire ; then lower the jack, loosen inner wheel
nuts and jack up the vehicle again to remove
inner tire .
3 Mounting the tire
1. Clean the following sections before mounting
the wheel. If they are dirty, the wheel nuts could
become loose during driving.
Threads on wheel bolts and nuts
Spherical surface of wheel nuts
Disc wheel mounting surface
Disc wheel mating surface
Wheel nut contact surface on disc wheel
Disc wheel inside surface
Guide sections on hub
WARNING
• Fit the socket wrench securely on the
wheel nut. If fitted improperly, the wrench
will slip off the nut, and could cause injury.
• Do not loosen the wheel nuts too much or
you could damage the threads.
WARNING
• Do not rotate the jacked-up wheel if the
vehicle has a limited-slip differential.
Power would be transmitted to the wheel
in contact with the ground, and the vehicle
could move as a result.
• When removing wheels, be careful not to
damage the wheel bolts and the threads of
the inner wheel nuts.
Z09307
Z09031
Z09309
