14-4 Service data
Service data
Description Standard value
Engine idling speed 625 to 675 rpm
Belt tension [amount of deflection
under a 98 N (22 lbs., 10 kgf) pres-
sure at the point midway between
pulleys]
Fan belt
Vehicles without
air conditioner
New belt (when installed):
9 to 11 mm
(0.35 to 0.43 in.)
Used belt (when
inspected or reinstalled):
11 to 13 mm
(0.43 to 0.51 in.)
Vehicles with air
conditioner
New belt (when installed):
7 to 9 mm
(0.28 to 0.35 in.)
Used belt (when
inspected or reinstalled):
10 to 11 mm
(0.39 to 0.43 in.)
Coolant quantity
Approx. 16 liters
(17 qts)
Clutch pedal play (at center of pedal pad)
0.2 to 4 mm
(0.0079 to 0.16 in.)
Brake pedal play (at center of pedal pad)
0.1 to 3 mm
(0.0039 to 0.12 in.)
Fully depressed brake pedal to floor clearance 20 mm (0.79 in.) or more
Parking brake lever stroke
(When pulled with a force of 295 N {66 lbs., 30 kgf}.)
7 to 9 notches
Steering wheel play (as measured on the periphery
of steering wheel)
When engine is
turned off
10 to 20 mm
(0.39 to 0.79 in.)
When engine is
idling
5 to 50 mm
(0.20 to 1.97 in.)
Tire tread groove depth 1.6 mm (0.06 in.) or more
Wheel nut tightening torque
440 to 540 N·m
(325 to 398 ft.lbs.,
45 to 55 kgf·m)
Tire inflation pressure
FE83
FE84
LT215/85R16-
10PR
(Load Range E)
550 kPa
(80 psi, 5.5 kgf/cm
2
)
FE85
215/75R17.5
124/123L
(Load Range F)
690 kPa
(100 psi, 7.0 kgf/cm
2
)
FG
LT235/85R16-
10PR
(Load Range E)
550 kPa
(80 psi, 5.5 kgf/cm
2
)
FE_FG.book Page 4 Wednesday, January 14, 2009 7:08 PM
