For emergencies
6-13
6
3. Rotate the jack by hand until the flange portion (B) fits in
the groove (C) at the top of the jack.
4. Insert the bar (D) into the wheel nut wrench (E). Then put
the end of the bar into the shaft’s jack end, as shown in the
illustration.
Slowly rotate the wheel nut wrench until the tire is raised
slightly off the ground surface.
WARNING
!
● Stop jacking up the vehicle as soon as the tire is
raised off the ground. It is dangerous to raise the
vehicle any higher.
● Do not get under your vehicle while using the jack.
● Do not bump the raised vehicle or leave it sitting on
the jack for a long time. Both are very dangerous.
● Do not use a jack except the one that came with your
vehicle.
● The jack should not be used for any purpose other
than to change a tire.
