Generic Terms and Abbreviations
Unless specially noted, the following generic terms and abbreviations are used in this
manual.
Generic term/abbreviation Details of generic term/abbreviation
PLC CPU Generic term for PLC CPU on which AD75 can be mounted.
AD75
Generic term for positioning module AD75P1-S3, AD75P2-S3, AD75P3-S3, A1SD75P1-S3,
A1SD75P2-S3, and A1SD75P3-S3.
The module type is described to indicate a specific module.
Peripheral device
Generic term for DOS/V personal computer that can run the following "AD75 Software
Package".
AD75 software package
Generic term for "SW1IVD-AD75P type positioning module software package" and "GX
Configurator-AP Version 1 (SW0D5C-AD75P-E)."
Drive unit Abbreviation for pulse input compatible drive unit (servo amplifier, stepping motor).
Manual pulse generator Abbreviation for manual pulse generator (prepared by user).
Data link system Abbreviation for MELSECNET (II) and MELSECNET/B data link system.
Network system Abbreviation for MELSECNET/10 network system.
I/F Abbreviation for interface.
17-segment LED 17-segment display mounted on upper front of AD75.
DOS/V personal computer IBM PC/AT
R
and compatible DOS/V compliant personal computer.
Personal computer Generic term for DOS/V personal computer.
Workpiece Generic term for moving body such as workpiece and tool, and for various control targets.
Axis 1, axis 2, axis 3 Indicates each axis connected to AD75.
1-axis, 2-axis, 3-axis
Indicates the number of axes. (Example: 2-axis = Indicates two axes such as axis 1 and axis 2,
axis 2 and axis 3, and axis 3 and axis 1.)
