1 - 12
MELSEC-A
1 PRODUCT OUTLINE
1.2 Flow of system operation
1.2.1 Flow of all processes
The positioning control processes, using the AD75, are shown below.
AD75 software
package
Servo, etc.
AD75
PLC CPU
GPP function soft-
ware package
Design
Understand the functions and performance, and determine the positioning operation method
(system design)
1)
Preparation
Installation, wiring, single module test
Setting of the:
· Parameters
· Positioning data
· Start block data
· Condition data
Creation of sequence
program for operation
Refer to (Note)
2)
3) 4)
5) 6)
7) 8)
Writing of setting data
Writing of program
Monitoring with
test operation,
and debugging
of setting data
Connection confirmation
Test operation
Monitoring and
debugging of
operation
program
9)
10)
11)
Operation
Monitor
Actual operation
Maintenance
Monitor
Disposal
(Note)
When not using the
AD75 software
package, carry out
setting, monitoring
and debugging of
the data in 3) with
the GPP function
software package.
Maintenance
