2 SYSTEM CONFIGURATION
2.1 General image of system
The general image of the system, including the AD75, PLC CPU and peripheral
devices is shown below.
(The Nos. in the illustration refer to the "No." in section "2.2 List of configuration
devices".
1
6
5
6
Extension
system
Converter
RS-232 cable
RS-422 cable
Conversion cable
* Only when using
A1SD75P -S3
Extension
cable
Positioning
module
I/O module
Main base unit
*
2
CPU module
*
1
*
3
REMARK
*
1
Refer to section "2.3 Applicable system" for the CPU modules that can be used.
*
2
Refer to the CPU module User's Manual for the base units that can be used.
*
3
Refer to the AD75 Software Package Operating Manual.
