This CME Error status gives information to the functioning of Mobile
Equipment (ME), please refer to the GSM modem manual for more
details.
CMS Error
This value gives error information relevant to the Mobile Equipment
(ME) or Network, please refer to the GSM modem manual for more
details.
Table 3.2: Mobile Equipment Error Codes
Value Description Value Description
-1 No Error 17 SIM PIN2 Required
0 Phone Failure 18 SIM PUK2 Required
1 No Connection to Phone 20 Memory Full
2 Phone-Adaptor Link Reserved 21 Invalid Index
3 Operation Not Allowed 22 Not Found
4 Operation Not Supported 23 Memory Full
5 PH-SIM PIN Required 24 Text String Too Long
10 SIM Failure 25 Invalid Characters in Text String
11 SIM PIN Required 26 Dial String Too Long
12 SIM PUK Required 27 Invalid Characters in Dial String
13 SIM Failure 30 No Network Service
14 SIM Busy 31 Network Timeout
15 SIM Wrong 100 Unknown
16 Incorrect Password ...256
All other values below 256 are reserved.
Table 3.3: Mobile Equipment and Network Error Codes
Value Description Value Description
-1 No Error 315 SIM Wrong
0 - 127 GSM 04.11 Annex E-2 Values 316 SIM PUK Required
128 - 256
GSM 03.40 Subclause 9.2.3.22
values
317 SIM PIN2 Required
300 ME Failure 318 SIM PUK2 Required
301 SMS Service of ME reserved 320 Memory Failure
302 Operation Not Allowed 321 Invalid Memory Index
303 Operation Not Supported 322 Memory Full
304 Invalid PDU Mode Parameter 330 SMSC Address Unknown
305 Invalid Text Mode Parameter 331 No Network Service
310 SIM not Inserted 332 Network Timeout
311 SIM PIN Required 340 No +CNMA acknowledgment expected
312 PH-SIM PIN Required 500 Unknown Error
313 SIM Failure ... 511
Unused Values in the range from 256 to 511
are Reserved.
314 SIM Busy 512 (+) Manufacturer Specific
GSM S t tasu
CME rE
1-
ror
GSM S t tasu
CMS rE
1-
ror
