α2
Simple Application Controllers
Function Blocks 6
6 - 79
6.33 Control Display Manager
Display Manager controls the sequence of user screens to be displayed according to the
signal that specifies each user screens. When N04 has been turned ON, Display Manager
becomes effective. The user screen set with Display Manager is displayed on the
α2 series.
The displayed user screen can be composed up to 10 Display function blocks.
However, the Display Manager can only be set using a combination of an
α2 Series
Controller and the Al-PCS/WIN-E Vr 2.00. The Control Display Manager cannot be
programmed using the controller alone.
.
Insert CDP function block area
Add DP function block area
To Next Page
