α2 Simple Application Controllers
Function Blocks 6
6 - 17
Setup of the One Shot Function Block directly from the α2 Series Controller
1 ) Allocate the input pin to be used for the function block.
2 ) Press the “OK” key with the cursor in the function block. The function block edit screen is
displayed as shown.
3 ) Press the “OK” key to set the Time unit for the delayed output.
4 ) Press the “OK” key having selected the value for the one shot time unit and return to the
function block edit screen. Using the “ and ” keys highlight the Setup FB and press the
“OK” key. The screen displayed is shown.
5 ) Select the One Shot or Priority option using the “ and ” Keys and press the “OK” key.
The One Shot time can be entered using the “+” or “-” keys.
6 ) The Priority can be entered using the “ or ” keys.
7 ) Press the “OK” key to accept the time figures and subsequently press the “ESC” key to
return to the function block edit screen.
B001:OS
Se t up FB
Change No
De l e t e FB
Time uni t
10 ms
Time uni t
10ms
1s
0
OneSh o
Pr i or i t y
t
B001 :OS
OneSho
T= 1s
t
t= 0s
B001 :OS
0.
0.
Pr i or i t y
B001 :OS
Time
Input
