Setup of the Pulse Width Modulation Function Block directly from the α2 Series Controller
1 ) Allocate the input pin to be used for the function block.
2 ) Press the “OK” key with the cursor in the function block. The function block edit screen is
displayed as shown.
3 ) Press the “OK” Key and enter the function block settings using the “Up and Down” keys.
4 ) Press the “OK” key with Period highlighted and the user can enter a T and t value using
the “ , , + and -” keys.
5 ) Press the “OK” key to return to the function block settings screen. Highlight the Duty option
using the “ 0 and ” keys. The Duty can be entered by pressing the “OK” key. A Directset
value, Analog In or FB value can be entered.
Press the “ESC” key until the user returns to the function block diagram.
