To remove
1. Remove the clips (A), and then remove the
upper cover (B).
2. Remove
the clips (C), and then remove the
air duct (D).
To install
1. Install the air duct (A), and then tighten the
clips (B).
2. Turn
the upper cover over. Squeeze the head
of the moulding clip (C) with pliers and re-
move the moulding.
3. Install
the upper cover, and then attach the
moulding (D).
NOTE
l
Attach
the moulding with the wide part to-
wards the front of the vehicle.
4. Install the clips (E).
During cold weather
E01010900068
The capacity of the battery is reduced at low tem-
peratures.
This is an inevitable result of its chemi-
cal and physical properties.
This is why a very cold battery, particularly one
that is not fully charged, will only deliver a fraction
of the starter current which is normally available.
Maintenance
8-09
8
