9 REPLACEMENT PARTS
LIST
Notes :
1. Be sure to make your orders of replacement parts
according to this list.
2. Important safety notice: Components, identified by
mark
have special characteristics important for safety. When
replacing any of these components, use only
manufacturer´s specified parts.
3. Location keys in the remarks column indicates the general
location of the parts shown in the exploded drawing, as in a
road map.
4. The marking (RTL) indicates that Retention Time is limited
for this item. After the discontinuation of assembly in
production, the item will continue to be available for a
specific period of time. The retention period of availability is
dependent on the type of assembly, and in accordance with
the laws governing part and product retention. After the end
of this period, the assembly will no longer be available.
Ref.
No.
Part No. Part Name & Description Remarks
[E6965] Main/Display Block
IC´s and TRANSISTORs
IC20 YEAMLC72135C IC
IC201 YEAMSN761026 IC
IC203 C0ABBB000179 IC
IC204 YEAMM5243FT1 IC
IC205 C0ABBB000179 IC
IC206 YEAMM5243FT1 IC
IC210 C0ABBB000179 IC
IC601 C2BBGF000287 IC
IC602 MN1382KTX IC
IC603 C0JBAM000048 IC
IC604 C3EBCG000037 IC
IC703 MN1382QTX IC
IC704 YEAMA61W12ST IC
IC801 YEAMHA12181F IC
IC901 YEAMSM6786 IC
PA51 YEP0PTA514B0 Electronic Tuner
Q221 B1GBHBEA0004 Transistor
Q222 B1ABCF000042 Transistor
Q223 B1GDCFLL0010 Transistor
Q321 B1GBHBEA0004 Transistor
Q401 B1GDCFJN0004 Transistor
Q402 B1GBCFGG0001 Transistor
Q403 B1ABCF000044 Transistor
Q404 B1ABCF000042 Transistor
Q405 B1ABCF000044 Transistor
Q406 B1ABCF000044 Transistor
Q407 B1ABCF000042 Transistor
Q408 B1ABCF000044 Transistor
Q711 B1GDCFLL0010 Transistor
Q712 YEANC114YKX Transistor
Q713 B1ABCF000042 Transistor
Q720 YEANBP1F3PT Transistor
Q721 2SD245300L Transistor
Q722 2SB1398QTA Transistor
Q723 2SB1398QTA Transistor
Q724 B1GDJEGJ0002 Transistor
Q725 YEANBP1F3PT Transistor
Q731 B1ABCF000044 Transistor
Q732 YEANC114YKX Transistor
Q741 B1BBAC000007 Transistor
Q771 2SD245300L Transistor
Q772 2SD0601AHR Transistor
Q773 YEAN2SD1856 Transistor
Q774 2SB1398QTA Transistor
Ref.
No.
Part No. Part Name & Description Remarks
Q775 2SD0601AHR Transistor
Q911 YEANHQ1F3PT1 Transistor
Q912 B1GDJEGJ0002 Transistor
Q913 2SB1398QTA Transistor
Q914 2SD0601AHR Transistor
DIODEs
D51 MA3X55500L Diode
D71 MA551TX Diode
D401 MA152WKTX Diode
D402 MAZ32700ML Diode
D403 MAZ32700ML Diode
D404 MAZ32700ML Diode
D603 MA3X152K0L Diode
D610 MA152WKTX Diode
D621 MA741TX Diode
D710 B0BA03300012 Diode
D711 YEADRD91M1T2 Diode
D712 MA152WKTX Diode
D731 YEADRD75M2T1 Diode
D732 MA741TX Diode
D733 YEADRD56M3T1 Diode
D773 YEADRD12M1T1 Diode
D774 B0BC5R100014 Diode
D775 B0EAKP000011 Diode
D776 B0EAKP000011 Diode
D779 B0EAKP000011 Diode
D901 MA3X152K0L Diode
CAPACITORs
C25 YECUS1H220JM Ceramic, 22PF 50WV
C26 YECUS1H150JM Ceramic, 15PF 50WV
C51 F1J1H221A672 Ceramic, 220PF 50WV
C53 ECEA1AKS221I Electrolytic, 220µF 10WV
C55 YECUS1E223KX Ceramic, 0.022µF 25WV
C56 YECUS1E223KX Ceramic, 0.022µF 25WV
C58 F1J1H1020024 Ceramic, 1000PF 50WV
C59 F1J1H1020024 Ceramic, 1000PF 50WV
C60 F1J1H103A513 Ceramic, 0.01µF 50WV
C71 F1J1H221A672 Ceramic, 220PF 50WV
C101 YECUS1C154KX Ceramic, 0.15µF 16WV
C102 YECUS1H153KX Ceramic, 0.015µF 50WV
C103 YECUS1C563KX Ceramic, 0.056µF 16WV
C105 F1J1H2R0A007 Ceramic, 2.0PF 50WV
C106 F1J1H101A672 Ceramic, 100PF 50WV
C162 F1J1H103A513 Ceramic, 0.01µF 50WV
C163 F1J1H103A513 Ceramic, 0.01µF 50WV
C166 F1J1H103A513 Ceramic, 0.01µF 50WV
C201 ECEA1AKA221I Electrolytic, 220µF 10WV
C202 ECEA1HKS2R2I Electrolytic, 2.2µF 50WV
C203 ECEA1HKA2R2I Electrolytic, 2.2µF 50WV
C204 YECUS1H390JM Ceramic, 39PF 50WV
C205 ECEA1EKA4R7I Electrolytic, 4.7µF 25WV
C206 YECUS1H390JM Ceramic, 39PF 50WV
C207 F1J1H681A672 Ceramic, 680PF 50WV
C208 F1J1H681A672 Ceramic, 680PF 50WV
C210 ECEA1HKA010I Electrolytic, 1µF 50WV
C211 ECEA1HKSR22I Electrolytic, 0.22µF 50WV
C212 ECEA1HKA010I Electrolytic, 1µF 50WV
C213 ECEA1ASN100I Electrolytic, 10µF 10WV
C214 F1J1H103A513 Ceramic, 0.01µF 50WV
C217 F1J1H682A675 Ceramic, 6800PF 50WV
C218 F1J1H821A672 Ceramic, 820PF 50WV
C220 ECEA1VSN2R2I Electrolytic, 2.2µF 35WV
C221 YECUS1C683KX Ceramic, 0.068µF 16WV
C222 ECEA1ASN100I Electrolytic, 10µF 10WV
C224 ECEA1HKS2R2I Electrolytic, 2.2µF 50WV
C225 ECEA1CKA100I Electrolytic, 10µF 16WV
C230 YECUS1C104KX Ceramic, 0.1µF 16WV
C231 YECUS1C104KX Ceramic, 0.1µF 16WV
C232 YECUS1E223KX Ceramic, 0.022µF 25WV
9
MITSUBISHI / CQ-JB3160AA
