Mitsubishi ECLIPSE 2011 User Manual

3-40
Features and controls
3
2. While pushing the slide (C) in the direction of the arrow,
install the top and bottom frames, then release the slide
(C). Make sure both of the frames are securely engaged.
3. Move the locking pin (D) to the position (2).
C
1- Stowed position
2- Installation position
3- Locked position
123D
