7-42
Vehicle care and maintenance
7
● Some fuses may not be installed on your vehicle, depend-
ing on the vehicle model or specifications.
● The table above shows the main equipment corresponding
to each fuse.
The fuse block does not contain spare 7.5 A, 10 A and 15
A fuses. If a fuse of one of these capacities blows, replace
it temporarily by borrowing the one that matches from:
7.5 A: Door mirror heater
10 A: Dome light (in engine compartment)
15 A: Power outlet
Replace the borrowed fuse as soon as possible.
Engine compartment fuse location table
2.4 liter & 3.8 liter models
21 Sunroof 20 A
22 — — —
23 Electric window control 7.5 A
24 Electric convertible top 15 A
25 — Spare fuse 20 A
26 — Spare fuse 30 A
27 — Spare fuse 30 A
No. Symbol Electrical system Capacity
Engine compartment fuse location
Front
