Vehicle care and maintenance
7-43
7
No. Symbol Electrical system Capacity
1 Fuse (+B)
80 A*
1
2 Radiator fan motor
30 A*
2
,
50 A*
3
3 Anti-lock braking system
60 A*
1
4 Ignition switch
40 A*
1
5 Power window control
30 A*
1
6 Front fog lights 15 A
7 Heated seat 20 A
8 Horn 15 A
9 Engine control 20 A
10 Air conditioning 10 A
11 Stop lights 7.5 A
12 Audio 30 A
13 Alternator 7.5 A
14 Hazard warning flasher 10 A
15 Automatic transaxle 20 A
16 Headlight high beam (right) 10 A
17 Headlight high beam (left) 10 A
18 Headlight low beam (right)
10 A*
4
,
20 A*
5
19 Headlight low beam (left)
10 A*
4
,
20 A*
5
20 Position light (right) 7.5 A
21 Position light (left) 7.5 A
22 Dome light 10 A
23 Radio 15 A
24 Fuel pump 15 A
25 Windshield wiper 30 A
26 Electric convertible top
40 A*
1
*
1
:
Fusible link
*
2
:
Fusible link (2.4 liter models)
*
3
:
Fusible link (3.8 liter models)
*
4
:
Except for vehicles with high intensity discharge headlights
*
5
:
Vehicles with high intensity discharge headlights
No. Symbol Electrical system Capacity
