ENGINE COOLING -
Water Pump <6A1>
14-16
WATER PUMP <6A1>
14100270370
REMOVAL AND INSTALLATION
Pre-removal and Post-installation Operation
D Engine Coolant Draining and Supplying
(Refer to P.14-10.)
D Power Steering Fluid Draining and Supplying
(Refer to GROUP 3 7 A - On-vehicle Service.)
D Radiator Removal and Installation (Refer to P.14-24.)
D A/C Compressor Removal and Installation
(Refer to GROUP 55.)
D Timing Belt Removal and Installation
(Refer to GROUP 11.)
D Engine Mount Bracket Removal a n d Installation (Refer
to GROUP 32.)
24 Nm
8 ´ 30
8 ´ 25
Bolt specifications
8 ´ 25
Screw diameter ´ length mm
49 Nm
12 Nm
18 Nm
39 Nm
39 Nm
Sealant:
Mitsubishi Genuine Part No.
MD970389 or equivalent
8 ´ 20
8 ´ 30
8 ´ 25
8 ´ 30
1
2
3
4
5
5
5
f3mm
Removal steps
1. Pressure tube connection
A
A
"
2. Power steering oil pump assembly
3. Power steering oil pump bracket
4. Engine support bracket
"
A
A
5. Water pump
