Micro KXZ-W series can connect indoor unit capacity up to 150%.
• Capacity from 80% to 150% is possible
FDC121KXZEN1-W
FDC121KXZES1-W
FDC140KXZEN1-W
FDC140KXZES1-W
FDC155KXZEN1-W
FDC155KXZES1-W
Number of connectable
1 to 8 units
1 to 10 units
Connectable capacity
97 - 181
112 - 210
124 - 233
Item
Model
-
2
-
Example: FDC 140 KXZ EN 1
Series No.
Application power source...See the specifications
Multi KX
Nominal capacity (nominal cooling capacity : 14.0kW)
Model name (Outdoor unit)
Example: FDT 28 KXZ E 1
Series No.
Application refrigerant...See the specifications
Application refrigerant...See the specifications
Application power source...See the specifications
Multi series
Nominal capacity (nominal cooling capacity : 2.8 kW)
Model name (Indoor unit : FDT, FDTC, FDK)
Note
For outdoor unit, EN60552-2 and EN60555-3 are not applicable as consent by the utility company or notification to the
utility company is given before usage.
-W
-W
1.2 How to read the model name
(1) Outdoor unit
(2) Indoor unit
1. GENERAL INFORMATION
1.1 Increased indoor unit connection capacity
1.3 Table of models
Capacity
Model
15 22 28 36 45 56 71 90 112 140 160
Ceiling cassette-4 way type
(FDT)
◯ ◯ ◯ ◯ ◯ ◯ ◯ ◯ ◯
Ceiling cassette-4 way compact type
(FDTC)
◯ ◯ ◯ ◯ ◯ ◯
Wall mounted type
(FDK)
◯ ◯ ◯ ◯ ◯ ◯ ◯ ◯
Outdoor units to be combined
FDC
FDC121KXZEN1-W, 140KXZEN1-W, 155KXZEN1-W
FDC121KXZES1-W, 140KXZES1-W, 155KXZES1-W
'20 • KX-T-373
-
3
-
