Mitsubishi FDTN508HES User Manual

218
FDTN-H
Liquid piping: ø9.52 (3/8")
(Flare connecting)
Gas piping: ø15.88 (5/8")
Terminal block
Opening for
electric wiring
Opening for
electric wiring
Holes for anchor bolt
(M10 × 4 pcs.)
Holes for drain
(ø9.52 × 3pcs.)
Electric wiring
Opening for piping
and electric wiring
Opening for piping
and electric wiring
Opening for piping
and electric wiring
(Flare connecting)
845
10
50
380 1515
340
55
15103
150
7050
47
3535
110
460
110
195
50
195
40
880
310222
40
L
2
L3
L4
L1
Air
inlet
Air inlet
Air outlet
Maintenance
space
150 580 150
50 15
15 50
50
50
5027
50 15
Models FDC258HEN3, 308HEN3, 308HES3
Required space for maintenance and air flow Minimum allowable space to the obstacles
Unit:mm
Mark
123
L1 Open Open 500
L2 300 5 Open
L3 100 150 100
L4 555
Installation
type
Notes
(1) Avoid the location where four sides are entirely
surrounded by walls.
(2) Fix the unit by anchor bolts without fail. Restrict
the protrusion length of anchor bolt to 15 mm
and under.
(3) When strong wind blows against the unit, direct
the discharge port at a right angle to the wind
direction.
(4) Secure the space of 1 m and over at the top of unit.
(5) Make the height of obstruction wall in front of
discharge port lower than the height of unit.
Unit: mm
VIEW A
Liquid piping: ø9.52 (3/8")
(Flare connecting)
Gas piping: ø15.88 (5/8")
(Flare connecting)
40
53
95
40
