196
FDTN-H
Model FDTN308HEN
Operation data
(3)
Item
Model
FDTN308H FDC306HEN3
Nominal cooling capacity
(1)
W 7100
Nominal heating capacity
(1)
W 7300
Power source 1 Phase, 220/240V, 50Hz
Cooling input kW 3.07/3.11
Running current (Cooling) A 15.6/16.3
Power factor (Cooling) % 89/79
Heating input kW 2.82/2.86
Running current (Heating) A 14.5/15.2
Power factor (Heating) % 88/78
Inrush current (L.R.A) A 89
Noise level
(4)
dB(A) Hi 41 Lo:35 56
Exterior dimensions
mm
Unit 260 × 840 × 840
844 × 950 × 340
Height × Width × Depth Panel 30 × 950 × 950
Net weight kg 30 (Unit:24 Panel:6) 69
Refrigerant equipment
– RC5532ENE1 × 1
Compressor type & Q’ty
Motor kW – 2.24
Starting method – Line starting
Heat exchanger Louver fins & inner grooved tubing Slitted fins & bare tubing
Refrigerant control Capillary tube Capillary tube
Refrigerant R22
Quantity kg Holding charged
1.3 [Pre-charged up to the piping length of 5m]
Refrigerant oil r – 1.63 (SUNISO 3GS)
Defrost control IC controlled de-icer
High pressure control High pressure regulator valve
Air handling equipment
Fan type & Q’ty
Turbo fan × 1 Propeller fan × 1
Motor W 30 × 1 60 × 1
Starting method Line starting Line starting
Air flow (Standard) CMM Hi:17 Lo:12 54
Fresh air intake Available –
Air filter, Q’ty Long life filter ×1(washable) –
Shock & vibration absorber Rubber sleeve (for fan motor) Rubber mount (for compressor)
Electric heater W – 40 (Crank case heater)
Operation control
Operation switch Wireless remote control switch – (Indoor unit side)
Room temperature control Thermostat by electronics –
Safety equipment Internal thermostat for fan motor. Internal thermostat for fan motor.
Frost protection thermostat.
Installation data mm Liquid line: φ9.52 (3/8″) Gas line: φ15.88 (5/8″)
Refrigerant piping size (in)
Connecting method Flare piping
Drain hose (Connectable with VP25) –
Insulation for piping Necessary (both Liquid & Gas lines)
Accessories Mounting kit. Wireless remote controller. Drain hose
Optional parts Decorative Panel
(2) This packaged air conditioner is manufactured and tested in conformity with the following standard. JIS B8616 “UNITARY AIR CONDITIONERS”
(3) The operation data indicate when the air conditioner is operated at 220V and 240V respectively.
(4) Indicates the value at mild mode.
Notes (1) The data are measured at the following conditions.
Item Indoor air temperature Outdoor air temperature
Standards
Operation DB WB DB WB
Cooling 27˚C 19˚C 35˚C 24˚C
Heating 20˚C – 7˚C 6˚C
ISO-T1, JIS B8616
FDTN308HEN
Internal protector for compressor.
Internal thermostat for fan motor.
Internal pressure relief valve for compressor.
