4.2 Removing the Battery
4.2.1 Removing the battery to GT2712-STWD, GT2710-
VTWD or GT2510-VTWD
Step1. Make sure that the GOT power is off.
Step2. The battery is stored in the GOT rear face. Open the battery
cover as shown below.
Step3. Unplug the battery connector from the GOT connector.
Step4. Push and close the battery cover until it clicks.
Battery coverBattery
Connector
Battery cover
Without a battery extension cable
Battery Connector
Black cable
Red cable
Battery cover
4.2.2 Removing the battery to GT2508-VTWD
Step1. Make sure that the GOT power is off.
Step2. The battery is stored inside the SD card cover on the side of
the GOT. Open the SD card cover as shown in the following
figure.
Step3. After removing the battery from the battery holder of the GOT,
unplug the battery connector from the GOT connector.
Step4. Close the SD card cover until it clicks.
SD card coverBattery
Connector
SD card cover
Battery
Connector
Black cable
Red cable
SD card cover
