Mitsubishi Mahindra GX3600 - Harness Layout

98
MECHANICAL STRUCTURE
19~21mm 44~45.5mm
8-2 Harness
Starter Switch
Glow Plug
Oil Switch
Head Lamp
Temp Gauge
Turn Unit
Fuse (60A)
Fuse Box
Harness E
Harness B
Turn Lamp (L.H.)
Rear Combi Lamp (L.H.)
Fuel Gauge
Turn Lamp (R.H.)
Rear Combi Lamp (R.H.)
Meter Ass'y
Combination Switch
Rear Combi Lamp
Turn Lamp
Battery
Battery Cord (-)
ETR sol.
Terminal L,S
Alternator
Alternator
Horn
Terminal B
Terminal ST
Terminal B
Starter Motor
Starter Motor
Terminal M
Safety Switch
Safety Switch
Brake Switch
Brake Switch
Fuel Pump
