MECHANICAL STRUCTURE
509 mm
301 mm
3-3 Clutch Control, Brake Control
1. Structure
Brake Pedal (RH)
Brake Pedak (LH)
Brake Rod
Brake Rod
Brake Rod
Clutch Rod
Release Shaft
Clutch Pedal
Release Shaft
Clutch Pedal
Clutch Rod
Parking Brake Lever
Brake Pedal
