MECHANICAL STRUCTURE
Spring
O-ring
Poppef
Hydraulic Power
Take off-in
Hydraulic Chart
Releaf Valve :
Hydraulic Power
Take off-out
(G3/8)
(M16 x 1.5)
(G3/8) (G3/8)
(G3/8)
Housing
Plug
* Plug (Rc1/4)
When installing a Hydraulic take off block,
install a plug (Rc1/4).
(It is not provided at shipment.)
15.2 MPa
(155 kgf/cm
2
)
+0.5
0
+5
0
*
7-7 Releaf Valve
1. Releaf Valve
