1 Introduction
1.1 Outline and Features of Analog Control
A
Common Items
B
FX
3UC
-4AD
C
FX
3U
-4AD-ADP
D
FX
3U
-4DA-ADP
E
FX
3U
-4AD-PT
-ADP
F
FX
3U
-4AD-TC
-ADP
G
PID Instruction (FNC 88)
FX 3U /FX 3UC Series PLC User's Manual - Analog Control Edition
Common Items
Analog output products of other Series
•FX
2NC-4DA • FX2N-5A
•FX
2N-4DA • FX0N-3A
•FX
2N-2DA
→ For a detailed description of the other analog output
products, refer to the corresponding manuals.
1.1.3 Temperature sensor input control
Use the PLC to check the workpiece/machine temperature measured with the thermocouple or the platinum
resistance thermometer sensor.
→ To judge whether a unit can be connected to the PLC, refer to Chapter 3 "System Configuration
Drawings of Analog Products."
Temperature sensor input products of FX
3U Series
•FX
3U-4AD-PT-ADP
→ For a detailed description, refer to E.
•FX
3U-4AD-TC-ADP
→ For a detailed description, refer to F.
Temperature sensor input products of other Series
•FX
2N-8AD • FX2N-2LC
•FX
2N-4AD-TC • FX2N-4AD-PT
→ For a detailed description of the other temperature sensor input products, refer to the
corresponding manuals.
Temperature data
(Analog data)
Temperature
sensor input,
special function
block or special
adapter
Temperature data
(Digital value)
Check the temperature
using the PLC.
Measure the
temperature of the
equipment.
FX 3U /FX 3 UC Series PLC
