Q SHC SHF INPUT Q SHC SHF INPUT Q SHC SHF INPUT Q SHC SHF INPUT
21 18 8.13 3.58 0.44 3234 7.47 3.29 0.44 3432 7.18 3.16 0.44 3498 6.89 3.03 0.44 3564
21 20 8.55 2.74 0.32 3366 7.97 2.55 0.32 3531 7.68 2.46 0.32 3630 7.39 2.36 0.32 3729
22 18 8.13 3.90 0.48 3234 7.47 3.59 0.48 3432 7.18 3.45 0.48 3498 6.89 3.31 0.48 3564
22 20 8.55 3.08 0.36 3366 7.97 2.87 0.36 3531 7.68 2.76 0.36 3630 7.39 2.66 0.36 3729
22 22 9.05 2.17 0.24 3498 8.47 2.03 0.24 3696 8.18 1.96 0.24 3762 7.89 1.89 0.24 3828
23 18 8.13 4.23 0.52 3234 7.47 3.88 0.52 3432 7.18 3.73 0.52 3498 6.89 3.58 0.52 3564
23 20 8.55 3.42 0.40 3366 7.97 3.19 0.40 3531 7.68 3.07 0.40 3630 7.39 2.95 0.40 3729
23 22 9.05 2.53 0.28 3498 8.47 2.37 0.28 3696 8.18 2.29 0.28 3762 7.89 2.21 0.28 3828
24 18 8.13 4.56 0.56 3234 7.47 4.18 0.56 3432 7.18 4.02 0.56 3498 6.89 3.86 0.56 3564
24 20 8.55 3.76 0.44 3366 7.97 3.51 0.44 3531 7.68 3.38 0.44 3630 7.39 3.25 0.44 3729
24 22 9.05 2.90 0.32 3498 8.47 2.71 0.32 3696 8.18 2.62 0.32 3762 7.89 2.52 0.32 3828
24 24 9.55 1.91 0.20 3630 8.96 1.79 0.20 3795 8.72 1.74 0.20 3878 8.47 1.69 0.20 3960
25 18 8.13 4.88 0.60 3234 7.47 4.48 0.60 3432 7.18 4.31 0.60 3498 6.89 4.13 0.60 3564
25 20 8.55 4.10 0.48 3366 7.97 3.82 0.48 3531 7.68 3.69 0.48 3630 7.39 3.55 0.48 3729
25 22 9.05 3.26 0.36 3498 8.47 3.05 0.36 3696 8.18 2.94 0.36 3762 7.89 2.84 0.36 3828
25 24 9.55 2.29 0.24 3630 8.96 2.15 0.24 3795 8.72 2.09 0.24 3878 8.47 2.03 0.24 3960
26 18 8.13 5.21 0.64 3234 7.47 4.78 0.64 3432 7.18 4.59 0.64 3498 6.89 4.41 0.64 3564
26 20 8.55 4.45 0.52 3366 7.97 4.14 0.52 3531 7.68 3.99 0.52 3630 7.39 3.84 0.52 3729
26 22 9.05 3.62 0.40 3498 8.47 3.39 0.40 3696 8.18 3.27 0.40 3762 7.89 3.15 0.40 3828
26 24 9.55 2.67 0.28 3630 8.96 2.51 0.28 3795 8.72 2.44 0.28 3878 8.47 2.37 0.28 3960
26 26 10.04 1.61 0.16 3762 9.46 1.51 0.16 3927 9.17 1.47 0.16 4010 8.88 1.42 0.16 4092
27 18 8.13 5.53 0.68 3234 7.47 5.08 0.68 3432 7.18 4.88 0.68 3498 6.89 4.68 0.68 3564
27 20 8.55 4.79 0.56 3366 7.97 4.46 0.56 3531 7.68 4.30 0.56 3630 7.39 4.14 0.56 3729
27 22 9.05 3.98 0.44 3498 8.47 3.73 0.44 3696 8.18 3.60 0.44 3762 7.89 3.47 0.44 3828
27 24 9.55 3.05 0.32 3630 8.96 2.87 0.32 3795 8.72 2.79 0.32 3878 8.47 2.71 0.32 3960
27 26 10.04 2.01 0.20 3762 9.46 1.89 0.20 3927 9.17 1.83 0.20 4010 8.88 1.78 0.20 4092
28 18 8.13 5.86 0.72 3234 7.47 5.38 0.72 3432 7.18 5.17 0.72 3498 6.89 4.96 0.72 3564
28 20 8.55 5.13 0.60 3366 7.97 4.78 0.60 3531 7.68 4.61 0.60 3630 7.39 4.43 0.60 3729
28 22 9.05 4.34 0.48 3498 8.47 4.06 0.48 3696 8.18 3.92 0.48 3762 7.89 3.78 0.48 3828
28 24 9.55 3.44 0.36 3630 8.96 3.23 0.36 3795 8.72 3.14 0.36 3878 8.47 3.05 0.36 3960
28 26 10.04 2.41 0.24 3762 9.46 2.27 0.24 3927 9.17 2.20 0.24 4010 8.88 2.13 0.24 4092
29 18 8.13 6.18 0.76 3234 7.47 5.68 0.76 3432 7.18 5.46 0.76 3498 6.89 5.24 0.76 3564
29 20 8.55 5.47 0.64 3366 7.97 5.10 0.64 3531 7.68 4.91 0.64 3630 7.39 4.73 0.64 3729
29 22 9.05 4.70 0.52 3498 8.47 4.40 0.52 3696 8.18 4.25 0.52 3762 7.89 4.10 0.52 3828
29 24 9.55 3.82 0.40 3630 8.96 3.59 0.40 3795 8.72 3.49 0.40 3878 8.47 3.39 0.40 3960
29 26 10.04 2.81 0.28 3762 9.46 2.65 0.28 3927 9.17 2.57 0.28 4010 8.88 2.49 0.28 4092
30 18 8.13 6.51 0.80 3234 7.47 5.98 0.80 3432 7.18 5.74 0.80 3498 6.89 5.51 0.80 3564
30 20 8.55 5.81 0.68 3366 7.97 5.42 0.68 3531 7.68 5.22 0.68 3630 7.39 5.02 0.68 3729
30 22 9.05 5.07 0.56 3498 8.47 4.74 0.56 3696 8.18 4.58 0.56 3762 7.89 4.42 0.56 3828
30 24 9.55 4.20 0.44 3630 8.96 3.94 0.44 3795 8.72 3.83 0.44 3878 8.47 3.73 0.44 3960
30 26 10.04 3.21 0.32 3762 9.46 3.03 0.32 3927 9.17 2.93 0.32 4010 8.88 2.84 0.32 4092
31 18 8.13 6.83 0.84 3234 7.47 6.27 0.84 3432 7.18 6.03 0.84 3498 6.89 5.79 0.84 3564
31 20 8.55 6.16 0.72 3366 7.97 5.74 0.72 3531 7.68 5.53 0.72 3630 7.39 5.32 0.72 3729
31 22 9.05 5.43 0.60 3498 8.47 5.08 0.60 3696 8.18 4.91 0.60 3762 7.89 4.73 0.60 3828
31 24 9.55 4.58 0.48 3630 8.96 4.30 0.48 3795 8.72 4.18 0.48 3878 8.47 4.06 0.48 3960
31 26 10.04 3.62 0.36 3762 9.46 3.41 0.36 3927 9.17 3.30 0.36 4010 8.88 3.20 0.36 4092
32 18 8.13 7.16 0.88 3234 7.47 6.57 0.88 3432 7.18 6.32 0.88 3498 6.89 6.06 0.88 3564
32 20 8.55 6.50 0.76 3366 7.97 6.06 0.76 3531 7.68 5.83 0.76 3630 7.39 5.61 0.76 3729
32 22 9.05 5.79 0.64 3498 8.47 5.42 0.64 3696 8.18 5.23 0.64 3762 7.89 5.05 0.64 3828
32 24 9.55 4.96 0.52 3630 8.96 4.66 0.52 3795 8.72 4.53 0.52 3878 8.47 4.40 0.52 3960
32 26 10.04 4.02 0.40 3762 9.46 3.78 0.40 3927 9.17 3.67 0.40 4010 8.88 3.55 0.40 4092
INDOOR INDOOR
35 40 43 46
DB(:) WB(:)
CAPACITY : 8.3(KW) SHF : 0.62 INPUT : 3300(W)
OUTDOOR DB(:)
MSH-30RV - : MUH-30RV - (220V)
E1E1
PERFORMANCE DATA COOL operation
NOTE Q : Total capacity (kW) SHF : Sensible heat factor DB : Dry-bulb temperature
SHC : Sensible heat capacity (kW) INPUT : Total power input (W) WB : Wet-bulb temperature
OB272-1.qxp 02.1.26 1:22 PM Page 32
