OPERATIONS AFTER ENGINE IS WARMED UP
PERIODIC INSPECTION AND MAINTENANCE
2-55
Specified Engine Oil
• ACEA classification : "For service A1/B1,
A3/B3, A3/B4 or A5/B5"
• API classification: "For service SG" or
higher
Total quantity (Includes volume inside oil fil-
ter and oil cooler):
<6G74> 4.6 L
<6B31, 4G64> 4.3 L
NOTE: SAE 0W-30, 5W-30, and 5W-40 engine
oils can only be used if they meet ACEA A3/B3,
A3/B4 or A5/B5 and API SG (or higher) specifica
-
tion.
8. Install the engine oil filler cap.
9. Check engine oil level.
E4. REPLACE ENGINE OIL FILTER
M6020600401198
<4D56, 4M41>
1. Start the engine and allow it to warm up until the
temperature of the coolant reaches 80
°C to 90
°C.
Use care as oil could be hot.
2. Remove the engine oil filler cap.
3. Remove the under skid plate and engine room
under cover.
4. Remove the engine oil pan drain plug to drain
engine oil.
5. Use special tool oil filter wrench (MH061590) to
remove the engine oil filter.
6. Clean the filter bracket side mounting surface.
7. Apply a small amount of engine oil to the O-ring of
the new engine oil filter.
Oil filter number:
<4M41> 1230A046
<4D56> 1230A045
8. Once the O-ring of the oil filter is touching the
flange, use the commercially available tool to
tighten to the specified torque.
Tightening torque:
approximately 3/4 turn (22 ± 2 N⋅m)
9. Install the engine oil pan drain plug and refill the
engine oil.
10.Install the engine oil filler cap.
11.Race the engine 2−3 times, and check to be sure
that no engine oil leaks from installation section of
the engine oil filter.
12.Install the under skid plate and engine room
under cover.
<6G74>
1. Start the engine and allow it to warm up until the
temperature of the coolant reaches 80
°C to 90
°C.
2. Remove the engine oil filler cap.
3. Remove the under skid plate and engine room
under cover.
Use care as engine oil could be hot.
4. Remove the engine oil pan drain plug to drain
engine oil.
To Next Page
