Mitsubishi Pajero Workshop Manual

ABS <4WD> -
Troubleshooting
35B-25
Termi-
nal
No.
Normal conditionInspection conditionsCheck item
37 ABS valve relay output Ignition
switch: ON
When system abnormality is
detected and relay is off
System voltage
When relay is on approx. 1
second after engine starts
2 V or less
39 Brake warning lamp output Ignition
When lamp is switched off 2 V or less
switch: ON
When lamp is illuminated System voltage
40 Control solenoid valve OUT (RL) Ignition switch: ON System voltage
41 Control solenoid valve OUT(FR) Ignition switch: ON System voltage
46 Center differential lock switch
input <Super Select 4WD-II>
Ignition
switch: ON
Transfer selector lever position:
2H, 4H
System voltage
Transfer selector lever position:
4HLc, 4LLc
2 V or less
4WD detection switch input
<Part time 4WD>
Ignition
switch: ON
Transfer selector lever position:
2H
System voltage
Transfer selector lever position:
4H
2 V or less
47 Diagnosis select input
When the MUT- II is connected 1 V or less
When the MUT- II is not connected Approx. 12 V
48 Valve relay monitor Ignition switch: ON System voltage
50 ABS warning lamp output Ignition
When lamp is switched off System voltage
switch: ON
When lamp is illuminated 2 V or less
51 Control solenoid valve IN (RL) Ignition switch: ON System voltage
52 Control solenoid valve IN (FR) Ignition switch: ON System voltage
