PL-AK INDOOR UNITS WITH PUG OUTDOOR UNITS
MODELS PL18AK PL24AK PL30AK PL36AK PL42AK
Item Unit Cooling Cooling Cooling Cooling Cooling
Electrical Circuit
Voltage V 208/230 208/230 208/230 208/230 208/230
Frequency Hz 60 60 60 60 60
Total Input kW 1.82 2.38 2.85 3.34 4.35
Indoor Fan Current A 0.8 0.8 0.9 1.0 1.4
Booster Heater Current A -- -- -- -- --
Outdoor Fan Current (FLA) A 0.5 0.5 0.5 1.4 1.4
Compressor Current (230v) A 7.3 9.6 12.6 14.0 16.4
Refrigerant Circuit
Condensing Pressure PSIG 223 270 283 280 267
Suction Pressure PSIG 84 85 80 82 71
Discharge Temperature °F 165 191 197 190 192
Condensing Temperature °F 91 112 108 111 104
Suction Temperature °F 60 58 59 62 50
Refrigerant Pipe Length FT 25 25 25 25 25
Refrigerant Charge -- 3 lbs 14 oz 4 lbs 3 oz 4 lbs 2 oz 4 lbs 10 oz 5 lbs 3 oz
Indoor Side
Intake Air Temperature
DB °F 80 80 80 80 80
WB °F 67 67 67 67 67
Discharge Air Temperature
DB °F 59 58 59 59 59
WB °F 58 57 57 57 57
Fan Speed RPM. 1490 1490 1490 1490 1490
Airflow (High) CFM 710 990 1060 1060 710
Outdoor Side
Intake Air Temperature
DB °F 95 95 95 95 95
WB °F -- -- -- -- --
Fan Speed RPM. 1050 1050 1050 1100 1100
Airflow (High) CFM 1785 1785 1835 2340 3320
Capacity BTU/H 20000 24000 28400 35600 41000
SHF -- 0.750.810.750.690.67
STANDARD OPERATING DATA
3
