Mitsubishi PUMY-P125YHM - Page 91

9191
Part numbers that are circled are not shown in the figure.
No. Part No. Part Name Specifi cation
Q'ty/set
Remarks
(Drawing No.)
Wiring
Diagram
Symbol
Recom-
mended
Q'ty
PUMY-P100/125/140
YHM
1
YHMA YHMA-BS
1
G R01 E44 221 FAN MOTOR 2 MF1, 2
G T7W E27 763 FAN MOTOR 2 2 MF1, 2
2 G R01 E08 115 PROPELLER FAN 2 2 2
3 G R01 E09 097 NUT 2 2 2
4 G T7W E12 259 REACTOR 3 3 3
ACL1,2,3
5 G R01 E14 413 CHARGE PLUG 2 2 2
6
G T97 415 747 COMPRESSOR
ANB33FDEMT 1
Including
RUBBER MOUNTS
MC
G T97 415 754 COMPRESSOR
ANB33FDKMT 11 MC
7 G R01 E13 410 STOP VALVE 3/8 1 1 1
8 G R01 E11 411 BALL VALVE 5/8 1 1 1
9 G R01 E06 450 STRAINER 1 1 1
10 G R01 E44 440 ACCUMULATOR 1 1 1
11 G R01 E12 490 OIL SEPARATOR 1 1 1
12 G R01 E26 425 CAPILLARY TUBE 1 1 1
[
2.5×
[
0.8×1000
13 G R01 E07 208 H.P SENSOR 1 1 1 63HS
14 G R01 E14 428 BYPASS VALVE 1 1 1
15 G R01 E00 209
LOW PRESSURE SWITHCH 1 1 1 63L
16
G T7W E32 242
SOLENOID VALVE COIL(BYPASS VALVE) 1 SV1
G R01 E57 242
SOLENOID VALVE COIL(BYPASS VALVE) 1 SV1
G T7W E51 242
SOLENOID VALVE COIL(BYPASS VALVE 1 SV1
17
G T7W E28 242
SOLENOID COIL(FOUR-WAY VALVE) 1 21S4
G R01 E58 242
SOLENOID COIL(FOUR-WAY VALVE) 1 1 21S4
18
G R01 E26 403 FOUR-WAY VALVE 1
G R01 E32 403 FOUR-WAY VALVE 1 1
19 G R01 E94 202 THERMISTOR 1 1 1 TH6, 7
20 G R01 E06 208
HIGH PRESSURE SWITCH 1 1 1 63H
21 G T7W E39 408 HEAT EXCHANGER 1 1 1
22 G T7W E23 346
NOISE FILTER CIRCUIT BOARD 1 1 1 N.F.
23
G T7W E54 310
CONVERTER CIRCUIT BOARD 1 CONV.B.
G T7W E63 310 CONVERTER CIRCUIT BOARD 11 CONV.B.
24
G T7W E32 313
POWER CURCUIT BOARD 1 P.B.
G T7W E42 313
POWER CURCUIT BOAR 1 1 P.B.
25 G —
ELECTRICAL PARTS BOX 111 (BK00C410G08)
26 G R01 E10 233 RESISTOR 1 1 1 RS
27
G R01 E02 254
MAIN SMOOTHING CAPACITOR 2 CB1,CB2
G T7W E21 255 MAIN SMOOTHING CAPACITOR 22 CB1,CB2
28
G T7W E11 259 REACTOR 1 ACL4
G R01 E31 259 REACTOR 1 1 ACL4
29 G R01 E02 311
TRANSMISSION POWER BOARD 1 1 1 M-P.B.
30
G R01 H76 310
MULTI CONTROLLER CIRCUIT BOARD 1 MULTI.B.
G R01 N56 310 CONTROLLER CIRCUIT BOARD 1 1 C.B.
31
G T7W E31 716 TERMINAL BLOCK
3P (M1, M2, S) 2 TB3,TB7
G R01 E27 246 TERMINAL BLOCK 3P (M1, M2, S) 22 TB3,TB7
32 G T7W E30 716 TERMINAL BLOCK 5P (L1, L2, L3, N,
;
) 1 1 1 TB1
33 G R01 E06 239 FUSE 250V 6.3A 2 2 2 F1, 2
34 G R01 H00 202
THERMISTOR (OUTDOOR PIPE) 1 1 1 TH3
35 G T7W E10 254 CAPACITOR 1 1 1 CK
36 G R01 E11 201
THERMISTOR (DISCHARGE) 1 1 1 TH4
RoHS
