5 SETTINGS AND PROCEDURES UP UNTIL OPERATION
(1) Setting switches
b7 b6 b5 b4 b3 b2 b1 b0
Bit
position
Contents OFF(0) ON(1)
b0
b1
Channel setting Refer to (a)
b2
Console
Software Not used Used
b3 Not used Fixed on OFF
b4 Console, debugger type VT VG
b5 Ctrl + C setting Disabled Enabled
b6 Not used Fixed on OFF
b7 Access possible time setting after Y reset 200 ms 2000 ms
(a) Console (Channel setting)
Bit position
b1 b0
Contents
OFF OFF Without console
OFF ON With console CH1
ON OFF With console CH2
ON ON Setting impossible
bF bE bD bC bB bA b9 b8
Bit
position
Contents OFF(0) ON(1)
b8 Not used Fixed on OFF
b9 Flash ROM write protection setting Without With
bA
bB
Not used Fixed on OFF
bC
bD
Channel setting Refer to (b)
bE
Debugger
Software Not used Used
bF Not used Fixed on OFF
(b) Debugger (Channel setting)
Bit position
bD bC
Contents
OFF OFF Without a debugger
OFF ON With debugger CH1
ON OFF With debugger CH2
ON ON Setting impossible
