Mitsubishi QX82

4 - 5 4 - 5
MELSEC-Q
4 I/O COMBINED MODULE
External connection Derating chart
2: Selection of left-hand (F) side provides the first half (X00 to X1F) LED indications, and selection of right-hand (L) side provides the
latter half (Y20 to Y3F) LED indications.
90
80
70
60
50
100
40
10 20 30 40 50055
A
mbient tem
p
erature
28.8VDC
(°C)
(%)
ON Ratio
