Appendix 1.2 Connectors, connector/terminal block converter modules
(1) 40-pin connectors
(a) A6CON1 soldering type, A6CON2 crimp-contact type 40-pin
connector
Unit: mm
(b) A6CON3 pressure-displacement type 40-pin connector
Flat cable
arrangement is in the
following sequence.
A1 B1 A2…
Unit: mm
69.48
8.25
22.5
10
