6 - 1 6 - 1
MELSEC-Q
6 BLANK COVER MODULE
6. BLANK COVER MODULE
This chapter provides the specifications of the blank cover module used to protect the
vacant slot (between I/O modules) of the base unit from dust.
Table 6.1 Blank Cover Module Specifications
Type
Item
QG60
Number of occupied I/O
points
Default: 16 points
(Can be changed to 0, 16, 32, 48, 64, 128, 256, 512, 1024 points by
"PLC system" of "PLC parameter".)
Application
Used as a dustproof cover for a slot not loaded with an I/O module
(especially a vacant slot between modules).
External
dimensions
H 98mm
W 27.4mm
D 90mm
Weight 0.07 kg
Load the blank cover module with the connector cover of the base unit fitted.
6
