8 SPECIFICATIONS OF CONNECTOR/TERMINAL BLOCK CONVERTER
MODULES
POINT
(1) The number of connectable I/O points is 32 for all connector/terminal block
converter modules.
Two connector/terminal block converter modules and two cables for
connector/terminal block converter modules are required for 64-point I/O
modules.
(2) Though the A1SX81(S2) is used either as a sink or source type, use the
A6TBX36-E, A6TBX54-E or A6TBX70-E.
The A6TBXY36, A6TBXY54 or A6TBX70 cannot be used.
(3) Though the A1SX82-S1 is used either as a sink or source type, the
A6TBXY36/XY54/X70 may be used only when the A1SX82-S1 is used as a sink
type.
When it is used as a source type, the A6TBXY36/XY54/X70 cannot be used.
(4) Though the A1SY82 and QY82P are source type output modules, use the
A6TBXY36 or A6TBXY54. The A6TBY36-E or A6TBY54-E cannot be used.
(5) In the A series, the positive common input module is separately labeled as a
sink type input module, and the negative common input module is separately
labeled as a source type input module.
(6) When using the A6TBX70 as I/O combined module, use at the input side.
(7) Tighten the module terminal screws to the following torque.
Terminal screw (M3.5 screw): Tightening torque 0.78N•m
(2) Cable
Type Details Weight Applicable Models
AC05TB 0.5 m, for sink modules 0.17kg
A6TBXY36
A6TBXY54
A6TBX70
AC10TB 1 m, for sink modules 0.23kg
AC20TB 2 m, for sink modules 0.37kg
AC30TB 3 m, for sink modules 0.51kg
AC50TB 5 m, for sink modules 0.76kg
AC80TB
8 m, for sink modules (common current not
exceeding 0.5 A)
1.2kg
AC100TB
10 m, for sink modules (common current
not exceeding 0.5 A)
1.5kg
AC05TB-E 0.5 m, for source modules 0.17kg
A6TBX36-E
A6TBY36-E
A6TBX54-E
A6TBY54-E
A6TBX70-E
AC10TB-E 1 m, for source modules 0.23kg
AC20TB-E 2 m, for source modules 0.37kg
AC30TB-E 3 m, for source modules 0.51kg
AC50TB-E 5 m, for source modules 0.76kg
