2 ENGINE - OUTLINE
Mitsubishi Diesel Engine S16R & S16R2 OPERATION & MAINTENANCE MANUAL
76
Pub. No. K29001-00320 Revision: 1
S16R-PTA2-C
■ Engine Front View, Engine Rear View
No. Name No. Name
Engine body
(1) Damper
Cooling system
(9) Coolant outlet
(2) Flywheel (10) Thermostat case
Fuel system (3) Governor actuator (11) Water pump
Lubrication system
(4) Breather
Inlet and
exhaust systems
(12) Intake port
(5) Bypass oil filter (13) Turbocharger
(6) Oil pan (14) Exhaust outlet
(7) Engine oil drain port
(8) Oil pump
(13)
(12)
(13)
(14)
(12)
(2)
(3)
(7)
(9)
(10)
(9)
(10)
(4)
(1)
(11)
(8)
(7)
(6)
(5)
