8 INSPECTION AND MAINTENANCE
Mitsubishi Diesel Engine S16R & S16R2 OPERATION & MAINTENANCE MANUAL
148
Pub. No. K29001-00320 Revision: 1
1 Clean the area around the fuel filter
with a waste cloth.
Fig. 8-30 Around Fuel Filter - Clean
2 Prepare a container to receive
spilled fuel and place it under the
fuel filter.
Fig. 8-31 Container to Receive Fuel
• The customer is required to prepare
the container.
3 Remove the fuel filter.
• Tool: Filter wrench
Fig. 8-32 Fuel Filter - Remove
• Remove it slowly so that fuel will not
spill.
4 Wipe off fuel on the fuel filter
installing surface of the filter
bracket with a waste cloth.
Fig. 8-33 Fuel Filter Installing Surface - Clean
5 Prepare a new fuel filter.
1) Check that the gasket is properly seated
in the groove.
2) Apply clean fuel on the fuel filter gasket.
Fig. 8-34 Fuel Filter Gasket
軽油用
Ｎｏ．
1
2
